          5. FUEL SYSTEM                                                          MXU 500 IRS




                                                                          Vacuum Hose
 PAIR SOLENOID VALVE

 REMOVAL/INSTALLATION

 Disconnect air supply hose and vacuum hose
 from the air solenoid valve, then remove the
 air solenoid valve from frame.




                                                PAIR Solenoid Valve   Air Supply Hose




 Installation is in the reverse order of
 removal.
