          6. CYLINDER HEAD/VALVES                              DOWNTOWN 125i



 ASSEMBLY
                                               Rocker Arm Shafts
 Apply engine oil to the rocker arms and
 rocker arm shafts.

 Install the rocker arms and shafts into the
 camshaft holder.

 · Install the exhaust valve rocker arm
     shaft on the "EX" side of the camshaft
     holder
   · Clean the intake valve rocker arm shaft
     off any grease before installation.




6-7
