18. MOVIE CARBURETOR EURO 3 MOVIE SYSTEM Float Pull float pin outs, then remove the float and float valve. Float Valve Float Pin Slow Jet Remove the slow jet. Remove choke jet. Remove main jet. Remove the needle jet holder. Main Jet/Needle Jet Holder/Needle Jet Remove the pilot screw, spring, washer and O-ring. Before pilot screw removal, slowly turn the pilot screw clockwise and count the number of turns until the screw is lightly seated. Make a note of how many turns were made so the screw can be reset correctly. Pilot Screw/Spring/Washer/O-ring 18-8
