9. KICK STARTER/DRIVE PULLEY/
CLUTCH/DRIVEN PULLEY ATV 50
DRIVE PULLEY
REMOVAL
Hold the flywheel with the universal holder
(see page 8-3) and remove the drive face nut
and washer.
Remove the drive pulley face.
Special tool:
Universal holder A120E00017
Drive Face Nut Drive Pulley Face
Movable Drive Face
MOVABLE DRIVE FACE
DISASSEMBLY
Remove the movable drive face and drive
pulley collar from the crankshaft.
Drive Pulley Collar
Ramp Plate
Remove the ramp plate.
9-9
