          12.LEFT CRANKCASE/CRANKSHAFT/                                      MXU 550EXi/MXU500i
    BALANCE SHAFT

                                                 Mark (on the Balance Shaft)
 INSTALLATION

 Install the balance shaft and crankshaft into
 the left crankcase.

 Align the mark on the balance shaft with
   the mark on the crankshaft.




                                                 Mark (on the Crankshaft)




12-5
