17. BRAKE SYSTEM MYROAD 700i
Clear Hose
Connect a clear hose to the left front caliper
air bleed screw and insert the other end of the
hose into a container.
Left Front Caliper Air Bleed Screw
Brake Lever
Loosen the air bleed screw and pump the
brake lever until the old brake fluid is
completely out of the brake system.
Close the air bleed screw and disconnect the
clear hose. Fill the reservoir with new brake
fluid to the upper end of the inspection
window.
Tighten the bleed screw to the specified
torque.
Torque: 0.6 kgf·m
Combination brake
Avoid spilling brake fluid on painted,
plastic or rubber parts and so on. Place a
rag over these parts whenever the system
is serviced.
Place the scooter on a level surface and keep
the handlebar straight.
17-5
