5. FUEL SYSTEM AGILITY CITY 125
FUEL TANK REMOVE
Remove the net-in box. ( 2-3)
Remove the frame center cover.
Remove the frame body cover. ( 2-3)
Remove the four bolts on the fuel tank, take
the upper seat lock off.
Disconnect the fuel unit wire connector.
Remove the fuel tank.
The installation sequence is the reverse of
removal.
Bolts Fuel Tank
FUEL STRAINER REMOVAL
Remove the fuel strainer from the fuel tank.
INSPECTION Fuel Unit Wite
Inspect if the fuel strainer is clogged and Connector
clean it with compressed air.
· When removing the fuel strainer, do
not allow flames or sparks near the
working area and drain the residual
gasoline into a container.
INSTALLATION
Install the fuel strainer with its arrow mark
toward the fuel pump.
Fuel Strainer
Arrow Mark
5-12
