K-PIPE 125
PREFACE
TABLE OF CONTENTS
This Service Manual describes the
GENERAL INFORMATION 1
technical features and servicing
procedures for the KYMCO K-PIPE 125. INSPECTION/ADJUSTMENT 2
LUBRICATION SYSTEM 3
Section 1 contains the precautions for all FUEL SYSTEM 4
operations stated in this manual. Read
them carefully before starting any ENGINE REMOVAL/INSTALLATION 5
ENGINE
operation. CYLINDER HEAD/VALVES 6
CYLINDER/PISTON 7
Section 2 is the inspection/ adjustment
ALTERNATOR/STARTER CLUTCH
procedures, safety rules and service 8
information for each part, starting from /CAM CHAIN TENSIONER
periodic maintenance. CLUTCH/GEAR SHIFT MECHANISM 9
CRANKCASE/CRANKSHAFT/
Section 3 and 4 state the servicing TRANSMISSION SYSTEM/STARTER 10
procedures and cautions for the removal SPINDLE
and installation of lubrication and fuel FRONT WHEEL/SUSPENSION/
systems. STEERING
11
CHASSIS
REAR WHEEL/BRAKE/SUSPENSION 12
Section 5 through 18 give instructions
for disassembly, assembly and inspection HYDRAULIC BRAKE 13
of engine, chassis frame and electrical FRAME COVER 14
equipment. IGNITION SYSTEM 15
ELECTRICAL
EQUIPMENT
Most sections start with an assembly or CHARGING SYSTEM 16
system illustration and troubleshooting STARTING SYSTEM 17
for the section. The subsequent pages LIGHTS/INSTRUMENTS/SWITCH
give detailed procedures for the section. ES/HORN/FUEL UNIT 18
Our company reserves the right to
make any alteration in the design.
The information and contents included
in this manual may be different from
the motorcycle in case specifications
are changed.
KWANG YANG MOTOR CO.,LTD.
QUALITY TECHNOLOGY DEPARTMENT
EDUCATION SECTION
