2. Turn the idle adjustment screw clockwise one turn past the recommended RPM setting; then turn it Adjusting Throttle counterclockwise to 1250-1350 RPM. Cable To adjust the throttle cable free-play, follow this proce- dure. 1. Slide the rubber boot away; then loosen the jam nut from the throttle cable adjuster. AF920D WARNING 2 Adjust the idle to the correct RPM. Make sure the engine is at normal operating temperature before adjusting the idle RPM. AL611D Engine/Transmission 2. Turn the adjuster until the throttle cable has proper Oil - Filter - Strainer free-play of 3-6 mm (1/8-1/4 in.) at the lever. OIL - FILTER The engine should always be warm when the oil is changed so the oil will drain easily and completely. 1. Park the ATV on level ground. 2. Remove the seat and left-side engine cover. 3. Remove the oil level stick/filler plug. ATV-0047 3. Tighten the jam nut against the throttle cable adjuster securely; then slide the rubber boot over the adjuster. Adjusting Engine RPM (Idle) KC0051A To properly adjust the idle RPM, a tachometer is nec- 4. Remove the drain plug from the bottom of the essary. To adjust idle RPM, use the following proce- engine and drain the oil into a drain pan. dure. NOTE: The idle adjustment screw is located on the right-hand side of the carburetor. 1. With the transmission in neutral, start the engine and 2-9 warm it up to normal operating temperature.
