13. FUEL SYSTEM/CARBURETOR/
FUEL PUMP/ FUEL TANK PEOPLE 250
Outlet Tube Vacuum Tube
FUEL PUMP REMOVAL
Remove met-in box and carrier.
Remove the body cover, center cover and rear
fender cover A.
Disconnect the fuel pump inlet, outlet and
vacuum tubes.
Remove the two fuel pump attaching nuts and
the fuel pump.
Nuts Inlet Tube
Inlet Screws
FUEL PUMP DISASSEMBLY
Remove the four fuel pump body screws.
Vacuum Tube Outlet
Disassemble the fuel pump.
13-18
