19. SWITCHES/HORN/FUELUNIT/THERMOSTATICSWITCH
/TEMPERATUREGAUGE/INSTRUMENTS/LIGHTS PEOPLE 250
SWITCHES
IGNITION SWITCH INSPECTION
Remove the frame front covers. ( 2-5)
Disconnect the ignition switch wire couplers.
Check for continuity between the wire
terminals.
Color Black/Wh
Red Green Black
Position ite
PARK
LOCK
OFF
ON
HEADLIGHT SWITCH INSPECTION
Remove the handlebar front covers. ( 2-3)
Disconnect the headlight switch wire
couplers. Check for continuity between the
wire terminals.
Color White / Brown/ Brown/
Position Blue Blue Brown White
P
H
STARTER SWITCH INSPECTION
Remove the handlebar front covers. ( 2-3)
Disconnect the starter switch wire couplers.
Depress the starter button and check for
continuity between the wire terminals.
Color Yellow/Red Green
Position
FREE
PUSH
ENGINE STOP SWITCH
Remove the handlebar front cover. ( 2-3)
Disconnect the wire couplers.
Checks for continuity between the engine
stop switch wire terminals.
Color Black/White Black/Green
Position
OFF
ON
19-3
