15. REAR BRAKE/REAR FORK/REAR
WHEEL/REAR SHOCK ABSORBER GRAND DINK 250
Upper Mount Bolts
REAR SHOCK ABSORBER
REMOVAL
Remove the rear carrier and hand rail. ( 2-3)
Remove the met-in box. ( 2-3)
Remove the two air cleaner bolts.
Remove the rear shock absorber upper mount
bolt.
Remove the right/left rear shock absorber
upper and lower mount bolts.
Remove the right and left rear shock
absorbers.
Lower Mount Bolts
Upper Mount Bolts
INSTALLATION
Install the rear shock absorbers in the reverse
order of removal.
Torque:
Upper Mount Bolt: 39.2N-m
Lower Mount Bolt: 19.629.4N-m
Lower Mount Bolts
15-7
