1. GENERAL INFORMATION ATV 50
FRAME
The following is the lubrication points for the frame.
Use general purpose grease for parts not listed.
Apply clean engine oil or grease to cables and movable parts not specified. This will avoid
abnormal noise and rise the durability of the motorcycle.
Rear Brake Cable
Front Brake Cable
Throttle Cable
Front Arm Bush Steering Column Upper
Front Arm Bush
Front Brake
camshaft/Oil
Seal/O-ring
Front Brake
camshaft/Oil
Seal/O-ring
Front Wheel
Oil Seal
Steering Column Lower
Front Wheel
Oil Seal
Steering knuckle/Thrust Steering knuckle/Thrust
Cover/Bush/Collar Cover/Bush/Collar
1-15
