5. FUEL SYSTEM ATV 50
Remove the jet needle by removing the
needle clip.
Check the jet needle and throttle valve for Needle Clip
wear or damage.
Needle Retainer
2nd Notch (STD)
Jet Needle
Throttle Valve
Carburetor Cap Rubber Seal
THROTTLE VALVE INSTALLA-TION
Install the jet needle on the throttle valve and
secure with the needle clip.
Install the rubber seal on the throttle cable
and then install the carburetor cap and
throttle valve spring.
Throttle Valve Spring
Connect the throttle cable to the throttle
valve.
Throttle Valve Throttle Cable
5-4
