          7. COOLING SYSTEM                                       MYROAD 700i


 Install 4 bolts of water pump, water pipes
 and clamp.

 Install the water pump cover and tighten the
 bolts to the specified toque.
 Torque: 1.3 kgf·m




                                                Clamp
