2. FRAME COVERS/ MYROAD 700i
EXHAUST MUFFLER
FRAME COVERS REMOVAL Nuts Damper Unit
SEAT
REMOVAL
Unlock the seat with the ignition key.
Open the seat.
Remove the two nuts and seat damper unit.
Remove the two nuts and the seat.
INSTALLATION Nuts
Installation is in the reverse order of the
removal.
After installation, check the seat installation Nuts
by moving the seat.
LUGGAGE BOX REMOVAL Screws Bolts
After removal the seat, side cover, carrier,
body cover, then you can remove the luggage
box.
Remove the screws and bolts.
Accessory Socket Connector
Raise the luggage box, disconnect the
luggage box light and accessory socket
connectors.
INSTALLATION
Installation is in the reverse order of removal.
Luggage box light Connector
2-3
