          3. INSPECTION/ADJUSTMENT                                                PEOPLE 125/150
                                                 When the engine misses or run erratic, adjust
                                                 the pilot screw.

 VALVE CLEARANCE                                             Cylinder Head Cover

   Inspect and adjust valve clearance while
   the engine is cold (below 35 ).
 Remove the center cover. ( 2)
 Remove the cylinder head cover. ( 7-4)




                                                                Bolts
 Turn the flywheel counterclockwise so that
 the "T" mark on the flywheel aligns with the
 index mark on the crankcase to bring the
 round hole on the camshaft gear facing up to
 the top dead center on the compression
 stroke.




 Inspect and adjust the valve clearance.                      Valve Wrench
 Valve Clearance: IN: 0.12mm
                    EX: 0.12mm
 Loosen the lock nut and adjust by turning the
 adjusting nut
 Special

 Valve Wrench

   · Check the valve clearance again after
     the lock nut is tightened.


 CARBURETOR IDLE SPEED
                                                               Throttle Stop Screw
   · The engine must be warm for accurate
     idle speed inspection and adjustment.
 Remove the inspection cover.
 Warm up the engine before this operation.
 Start the engine and connect a tachometer.
 Turn the throttle stop screw to obtain the
 specified idle speed.
 Idle Speed: 1700100rpm

3-5
