14. STEERING HANDLEBAR/FRONT WHEEL/FRONT
BRAKE/FRONT SHOCK ABSORBER/FRONT FORK PEOPLE/PEOPLE S 250
Brake Master Cylinders
STEERING HANDLEBAR
REMOVAL
Remove the handlebar front and rear covers.
( 2-3)
Remove the front and rear brake master
cylinder attaching bolts.
Bolts
Throttle Cable
Remove the four screws attaching the right
and left handlebar switches.
Disconnect the throttle cable from the throttle
grip and remove the throttle grip from the
handlebar.
Screws Throttle Grip
Lock Nut
Remove the handlebar lock nut then take out
the bolt and collar.
Remove the handlebar.
INSTALLATION Bolt Collar
Install the handlebar onto the steering stem
and install the handlebar collar, lock nut and
bolt.
Tighten the bolt to the specified torque.
Torque: 4050N-m
14-4
