          1. GENERAL INFORMATION                                                                                                    PEOPLE/PEOPLE S 250


SPECIFICATIONS

Name & Model No.                                 BA50AA                                      Air cleaner type & No                 Paper element, wet




                                                                    Fuel System
Motorcycle Name & Type                      PEOPLE S 250                                     Fuel capacity                               10.0 liters




                                                                                                  Carburetor
Overall length                                   2140mm                                             Type                                    CVK
Overall width                                     750mm                                             Piston dia.                              30
Overall height                                   1370mm                                             Venturi dia.                       30 equivalent
Wheel base                                       1480mm                                             Throttle type                      Butterfly type
                                          Water cooled 4-stroke,                                    Type                           Full transistor igniter
Engine type                               OHC engine




                                                                      Electrical Equipment

                                                                                              Ignition System
Displacement                                  251/249.1cc                                                       Ignition timing       Repeatedly
Fuel Used                                    92# nonleaded                                                      Contact breaker   Non-contact point type
                                                 gasoline
1 person (55kg)    Front wheel                      86                                                             Spark plug             NGK
                                                                                                                                        DPR7EA-9
weight (kg)        Rear wheel                      127
                      Total                         213
                                                                                                   Spark plug gap                        0.7mm
2 person (110kg) Front wheel                        93
                                                                                             Battery Capacity                          12V10AH
weight(kg)         Rear wheel                      175
                                                                                             Clutch Type                          Dry multi-disc clutch
                                                                      Power Drive System


                      Total                         268
                                                                                                                 Type                    Non-stage
                                                                                                sion Gear
                                                                                                Transmis-
                   Front wheel               110/70-16 52P
 Tires                                                                                                                                 transmission
                   Rear wheel                140/70-16 65P
Ground clearance                                 145mm                                                           Operation        Automatic centrifugal
                                                                                                                                          Type
Perform- Braking distance (m)                4.0m/30km/hr
ance      Min. turning radius                    2350mm                                                          Type             Two-stage reduction
                                                                                              Gear
                                                                                              Reduction




         Starting system                      Starting motor                                                     Reduction 1st           0.83~2.2
                                                                                                                 ratio     Fina             8.72
         Type                              Gasoline, 4-stroke
         Cylinder arrangement                Single cylinder                                                               l
         Combustion chamber type              Semi-sphere                                    Tire pressure                Front            1.75
                                                                   Device
                                                                   Moving




         Valve arrangement                       O.H.C.                                      (kgf/cm)                     Rear              2.0
         Bore x stroke (mm)                72.9 x 60/72.7 x 60                               Turning                      Left              45°
         Compression ratio                        10.3:1                                     angle                        Right             45°
         Compression pressure
         (kg/cm)                                  152              Brake system                                           Front         Disk brake
         Max. output (ps/rpm)                   20.1/7500          type                                                   Rear          Disk brake
Engine




         Max. torque (kg.m/rpm)                  2.1/6500                                    Suspension                   Front        Telescope
                                                                   Device
                                                                   Damping




                            BTDC                     9°                                      type                         Rear        Double swing
                Intake
         Port               ABDC                    40°                                      Shock absorber Front                       Telescope
         timing             BBDC                    42°                                      type                                     Double swing
                Exhaust                                                                                     Rear
                            ATDC                     7°            Frame type                                                          Under bone
         Valve            Intake                    0.1
         clearance (cold) Exhaust                   0.1
         Idle speed (rpm)                    1600100rpm
                                           Forced pressure &
         System
         Lubrication




                       Lubrication type
                                               Wet sump
                       Oil pump type      Inner/outer rotor type
                       Oil filter type      Full-flow filtration
                       Oil capacity              1.1 liters

         Cooling Type                         Water cooling

1-3
