11. COOLING SYSTEM
Screws
Set the two tabs under the air duct into the
grooves on the radiator lower part and then
secure the radiator with the two screws.
Fill the radiator with coolant. ( 3-12)
After installation, check for coolant leaks.
Air Duct
Water Pump
WATER PUMP
MECHANICAL SEAL (WATER SEAL)
INSPECTION
Inspect the telltale hole for signs of
mechanical seal coolant leakage.
If the mechanical seal is leaking, remove
the right crankcase cover and replace the
mechanical seal.
Right Crankcase Cover Telltale Hole
WATER PUMP/IMPELLER
REMOVAL
Remove the engine from the frame. ( 5-2)
11-8
