11. CARBURETOR ZX / SCOUT 50
Float Valve
FLOAT/FLOAT VALVE INSPECTION
Inspect the float for damage or fuel inside
the float.
Check the float valve seat for wear or
damage.
Float Seat
Main Jet
JETS/SCREWS REMOVAL
Before removing the throttle stop screw or
air screw, record the number of rotations
until it seats lightly. Then, remove them.
Remove the main jet and needle jet holder.
Throttle Stop Screw Air Screw
CARBURETOR PASSAGES CLEANING
Blow compressed air through all passages
of the carburetor body with an air gun.
11-9
