          2. FRAME COVERS/EXHAUST MUFFLER                                             AGILITY CITY 125


 FRAME BODY COVER REMOVAL                        Screws     Battery Cover      Screws
 Remove the two screws on the battery cover.
 Remove the battey cover
 Remove the six screws on the center cover
 Remove the center cover




                                                                   Center Cover

                                                          Bolts
 Remove the three bolts attaching the rear
 carrier.
 Remove the rear carrier.




                                                                                   Rear Carrier
                                                                       Rear Step
 Remove the two bolt attaching the lefe and
 right rear step.
 Remove the rear step




                                                                       Bolts
                                                                                  Left Side Skirt

 Remove the six screws attaching the left side
 and right side skirt
 Remove the left side and right side skirt
 During removal, do not pull the joint
   claws forcedly to avoid damage.
   When installing, be sure to connect the
   seat lock wire.


                                                    Screws                            Right Side Skirt


2-3
