1. GENERAL INFORMATION DINK 50/125
TORQUE VALUES
STANDARD TORQUE VALUES
Torque Torque
Item Item
kgf-m (N-m, lbf-ft) kgf-m (N-m, lbf-ft)
5mm bolt and nut 0.5 (5, 3.6) 4mm screw 0.3 (3, 2.2)
6mm bolt and nut 1 (10, 7.2) 5mm screw 0.4 (4, 2.9)
8mm bolt and nut 2.2 (22, 16) 6mm screw, SH bolt 0.9 (9, 6.5)
10mm bolt and nut 3.5 (35, 25) 6mm flange bolt and nut 1.2 (12, 9)
12mm bolt and nut 5.5 (55, 40) 8mm flange bolt and nut 2.7 (27, 20)
14mm bolt and nut 7 (70, 50) 10mm flange bolt and nut 4 (40, 29)
Torque specifications listed below are for important fasteners.
ENGINE
Torque
Thread dia. kgf-m (N-m,
Item Q`ty Remarks
(mm) lbf-ft)
MAINTENANCE:
Spark plug 1 10 1.2 (12, 8.6)
Tappet ADJ nut 2 5 0.9 (9, 6.5) Apply oil
Engine oil strainer screen cap 1 30 1.5 (15, 11) Apply oil
Engine oil filter cap bolt 3 6 1.2 (12, 8.6)
Engine oil drain plug 1 12 2.5 (25, 18)
Transmission gear oil drain bolt 1 10 1.3 (13, 9)
Transmission gear oil fill bolt 1 10 1.3 (13, 9)
LUBRICATION SYSTEM:
Oil pump screw 1 3 0.2 (2, 1.5)
COOLING SYSTEM:
Fan motor bolt 3 5 0.53 (5, 2.8)
Fan motor switch 1 16 1.8 (17, 13)
Water pump impeller 1 8 1.2 (12, 9) Left hand threads
CYLINDER HEAD:
Cylinder head cover 4 6 1.2 (12, 8.6)
Cylinder head nut (DINK 50) 4 6 0.7-1.1(10, 7.2) Apply oil
Cylinder head nut (DINK 125) 1 8 2 (20, 14) Apply oil
Tensioner sealing bolt 2 6 0.6 (6, 4)
Cam chain tensioner mounting bolt 2 6 1.2 (12, 8.6)
Cylinder head bolt 6 1 (10, 7.2)
(Cont'd)
1-8
