9. CLUTCH/GEAR SHIFT MECHANISM K-PIPE 125
Install the gear shift spindle and washer. Gear Shift Spindle
During installation, make sure that the return
spring aligns with the crankcase tab.
Spring
RIGHT CRANKCASE COVER Adjusting Bolt
INSTALLATION
Install the new O-ring and lock nut.
Lock Nut O-ring
Install the dowel pin and a new gasket. Gasket
Dowel Pins
Install the right crankcase cover and tighten Bolts
the cover bolts.
Install the kick-starter pedal.
Adjust the clutch (page 2-8).
9-12
