12. COOLING SYSTEM K-XCT 125i
Remove four bolts and the water pump Bolts Water Pump Cover
cover, gasket and two dowel pins.
Impeller (Left Hand Threads)
Remove the water pump impeller.
The impeller has left hand threads.
Seal Washer (Porcelain) Mechanical Seal
Inspect the mechanical (water) seal and seal
washer for wear or damage.
The mechanical seal and seal washer
must be replace as a set.
Impeller
12-12
