17. BATTERY/CHARGING SYSTEM K-XCT 125i
REGULATOR/RECTIFIER
WIRE HARNESS INSPECTION
Remove the luggage box (refer to the
"FRAME COVERS
REMOVAL/INSTALLATION" section in
the chapter 2).
Disconnect the regulator/rectifier connectors.
Check the connector for loose contacts of
corroded terminals.
Regulator/Rectifier
Measure the voltage between the Red/White
wire terminal and ground.
There should be same with battery voltage at
all times.
Regulator/Rectifier
17-7
