10. FINAL REDUCTION/
TRANSMISSION SYSTEM ATV 150/125
Bolts
Install the shift guide and drive select lever..
Install the starter idle gear starter clutch and
flywheel (refer to chapter 4).
Drive Select Lever/Shift Guide
Oil Filler Bolt Cylinder
Install and tighten the right case cover bolt.
Specified Gear Oil:
KYMCO SIGMA GEAR OIL 90#
Oil Capacity:
At disassembly:
400 cc (0.352 lmp qt, 0.424 US qt)
At change:
200 cc (0.176 lmp qt, 0.212 US qt)
Shift Gear Spindle Right Case Cover
Install and tighten the oil check bolt.
Torque: 1 kgf-m (10 N-m, 7.2 lbf-ft)
10-11
