8. STARTER MOTOR/GENERATOR/LEFT CRANK-
CASE COVER/STARTER CLUTCH QUANNON 125
STARTER CLUTCH REMOVAL
Remove the reduction pinion.
Remove the starter gear.
Starter Gear
INSPECTION
Measure the starter gear shaft I.D.
Service Limit: 22.062mm replace if over
Starter Gear
Measure the starter gear shaft O.D.
Service Limit: 42.534mm replace if below
Roller Micrometer Calipers
Measure the starter clutch roller O.D.
Service Limit: 9.95mm replace if below
8-4
