14.STEERING HANDLEBAR/FRONT WHEEL/FRONT BRAKE/FRONT SHOCK ABSORBER/FRONT FORK GRAND DINK 125/150 Bolts Holder FRONT BRAKE BRAKE MASTER CYLINDER REMOVAL Remove the handlebar covers. ( 2-6) First drain the brake fluid from the hydraulic brake system. Disconnect the front stop switch wire connector. Remove the brake fluid tube bolt. Remove the two bolts attaching the brake master cylinder Stop Switch Wire Connector Remove the brake master cylinder. · When servicing the brake system, use shop towels to cover rubber and plastic parts and coated surfaces to avoid being contaminated by brake fluid. · When removing the brake fluid tube bolt, be sure to plug the tube end to avoid brake fluid leakage. Snap Ring DISASSEMBLY Remove the brake lever bolt and the brake lever. Remove the piston rubber cover and snap ring from the brake master cylinder. Snap Ring Pliers (Close) Master Cylinder Spring Main Piston Remove the washer, main piston and spring from the brake master cylinder. Clean the inside of the master cylinder and brake reservoir with brake fluid. Snap Ring Rubber Cover 14-8
