6. ENGINE REMOVAL/INSTALLATION MXU 250R/300R
Remove the drive select shift to drive select
arm connecting bolt and nut.
Remove the two mounting nuts and drive
select shift.
Bolt/Nut Nuts
Speedometer Cable
Disconnect the speedometer cable.
Remove the three bolts at the drive sprocket Drive Sprocket Cover Bolts
cover and then remove the drive sprocket
cover.
Remove the two bolts on the drive sprocket.
Remove the drive sprocket and washer.
Bolts Drive Sprocket
6-3
