14. REAR WHEEL/SWING ARM/
HYDRAULIC BRAKE ATV 50
Tighten the two nuts with the nut wrench.
Special tool
Nut wrench A120F00010
Torque: 12 kgf-m (120 N-m, 86 lbf-ft)
Cotter Pin Washer
Install wheel hub, plate washer and nut
(wheel hub).
Torque: 7 kgf-m (70 N-m, 50 lbf-ft)
Install cotter pins.
Always use a new cotter pin.
Axle Nut
Do not loosen the axle nut after torque
tightening. If the axle nut groove id not
aligned with the cotter pin hole, align
groove with the hole by tightening ut on
the axle nut.
14-12
