20. ELECTRIC STARTER MYROAD 700i SERVICE INFORMATION GENERAL · Always turn the ignition switch to "OFF" before servicing the starter motor. The motor could suddenly start, causing serious injury. · The starter motor can be serviced with the engine in the frame. · When checking the starter system, always follow the steps in the troubleshooting flow chart. · A weak battery may be unable to turn the starter motor quickly enough, or supply adequate ignition current. · If the current is kept flowing through the starter motor to turn it while the engine is not cranking over, the starter motor may be damaged. TROUBLESHOOTING · Check for the following before troubleshooting: Loose battery and starter motor cable Discharged battery · The starter motor can turn with the following conditions: Ignition switch ON Engine stop switch in RUN Rear brake lever fully squeezed Side stand retracted Starter switch pushed Starter motor will not turn Check for loose or poorly Abnormal ·Poorly connected battery terminals. connected battery terminals and opened or shorted battery ·Open or short circuit in battery. cable. Normal (Go to following page) 20-2
