8. CYLINDER/PISTON PEOPLE 125/150
Measure the connecting rod small end I.D.
Service Limit: 15.06mm replace if over
PISTON RING INSTALLATION
Install the piston rings onto the piston.
Apply engine oil to each piston ring.
· Be careful not to damage or break the
piston and piston rings.
· All rings should be installed with the Top
markings facing up.
Second
· After installing the rings, they should
rotate freely without sticking.
Side Rail
Oil Ring
Side Rail
Top
Second
PISTON INSTALLATION
Remove any gasket remnant from the
8-7
