8. CYLINDER/PISTON PEOPLE 125/150
crankcase surface.
Be careful not to drop foreign matters
into the crankcase.
Piston Pin Piston
Install the piston, piston pin and a new piston
pin clip.
· Position the piston "IN" mark on the
intake valve side.
· Place a clean shop towel in the
crankcase to keep the piston pin clip
from falling into the crankcase.
Piston Pin Clip
Cylinder
CYLINDER INSTALLATION
Install the dowel pins and a new cylinder
gasket on the crankcase.
Coat the cylinder bore, piston and piston
rings with clean engine oil.
Carefully lower the cylinder over the piston
by compressing the piston rings.
· Be careful not to damage or break the
piston rings.
· Stagger the ring end gaps at 120° to the
piston pin.
Loosely install the cylinder base bolts.
Install the cam chain guide.
Install the cam chain tension. Bolt
Tighten the cam chain tension bolts.
8-8
