10. DRIVE PULLEY/DRIVEN PULLEY/CLUTCH UXV 500
INSPECTION
Weight rollers
Check each roller for wear or damage.
Measure outside diameter.
Service limit: 29.5 mm (1.18 in)
Movable drive face/Slide pieces/Drive
pulley face
Check the slide pieces and movable drive
face splines for wear, cracks or damage.
Check the ramp plate for cracks or damage.
Check the movable drive face and drive
pulley face cracks or damage.
10-10
