2. GENERAL INFORMATION ZX / SCOUT 50
FRAME Standard (mm) Service Limit (mm)
Item SC10AS SC10AS
Axle shaft runout 0.2
Radial
Front wheel rim runout
Axial
Front shock absorber spring free length 200.0 182.8
Rear wheel rim runout 2.0
Brake drum I.D. Front/rear 110 111
Brake lining thickness Front/rear 4.0/4.0 2.0/2.0
Brake disk runout Front/rear 0.30
Rear shock absorber spring free length 235.7 218.7
ELECTRICAL EQUIPMENT SC10AS
Capacity 12V3AH
Voltage 13.013.2V
Battery
Charging Standard 0.4A/5H
current Quick 4A/0.5H
Spark plug (NGK) BR8HSA
Spark plug gap 0.60.7mm
Primary coil 0.1530.187
Secondary coil
Ignition coil resistance (with plug cap) 6.9910.21K
Secondary coil
(without plug cap) 3.243.96K
Pulser coil resistance (20) 80160
Ignition timing 15.5°2°BTDC/2000rpm
2-7
