CARBURETOR

REAR FAIRINGS FOR KYMCO MXU 300 4T EURO II

FRONT FAIRINGS

(1) 64222-LLJ3-E00

RUBBER WIND SCREEN (11MM)

(2) 80100-LCA5-E00-C3R

FENDER REAR (BLUE)

(2) 80100-LCA5-E00-E4R

FENDER REAR (RED)

(2) 80100-LCA5-E00-GWR

FENDER REAR (DARK GREEN)

(2) 80100-LCA5-E00-YNR

FENDER REAR (YELLOW)

(2) 80100-LCA5-E00-YSR

FENDER REAR (SANDY)

(3) 80110-LBA7-900

RUBBER REAR FENDER

(4) 80121-LCA5-E01-N1R

MUDGUARD RIGHT FLOOR (BLACK BRUT)

(5) 80122-LCA5-E01-N1R

MUDGUARD LEFT FLOOR (BLACK BRUT)

(6) 80125-LBD4-900

COLLAR FLOOR

(7) 80200-LCA5-E00-C3R

MUDGUARD REAR (BLUE)

(7) 80200-LCA5-E00-E4R

MUDGUARD REAR (RED)

(7) 80200-LCA5-E00-GWR

MUDGUARD REAR (DARK GREEN)

(7) 80200-LCA5-E00-YNR

MUDGUARD REAR (YELLOW)

(7) 80200-LCA5-E00-YSR

MUDGUARD REAR (SANDY)

(8) 83500-LCA5-E01-N1R

COVER RIGHT SIDE (BLACK BRUT)

(9) 8360A-LCA5-E00

COUVERCLE GAUCHE

(9) 8360A-LCA5-E01-N1R

COVER LEFT SIDE (BLACK BRUT)

(10) 90110-LLB1-800-06

SCREW PAN (M06X16)(BLACK)

(11) 90653-LCA4-E00

CLIP MUDGUARD

(12) 90677-GAR1-C00

ECROU PRISONNIER M5

(13) 93404-06016-06

BOLT HEX (M06X16)(BLACK)

(14) 93404-06020-06

BOLT HEX (M06X20)(BLACK)

(15) 93903-34360

SCREW TAPPING (M04X12)(BLACK)

(16) 93903-35360

SCREW TAPPING (M05X16)

(17) 94050-LDE9-E00

NUT LOCK (M06)

(18) 93903-GFY6-C00

VIS A TETE PLATE CRUCIFORME TARAUDEUSE DE 09 (M04X14 NOIR)

	Part number	Description	Qty
# 1	64222-LLJ3-E00	RUBBER WIND SCREEN (11MM)	1,44 £ (1,64 €)
# 2	80100-LCA5-E00-C3R	FENDER REAR (BLUE)	84,37 £ (95,94 €)
# 2	80100-LCA5-E00-E4R	FENDER REAR (RED)	84,37 £ (95,94 €)
# 2	80100-LCA5-E00-GWR	FENDER REAR (DARK GREEN)	84,37 £ (95,94 €)
# 2	80100-LCA5-E00-YNR	FENDER REAR (YELLOW)	84,37 £ (95,94 €)
# 2	80100-LCA5-E00-YSR	FENDER REAR (SANDY)	84,37 £ (95,94 €)
# 3	80110-LBA7-900	RUBBER REAR FENDER	1,25 £ (1,42 €)
# 4	80121-LCA5-E01-N1R	MUDGUARD RIGHT FLOOR (BLACK BRUT)	39,64 £ (45,08 €)		Discount part 39,64 £ (45,08 €)
# 5	80122-LCA5-E01-N1R	MUDGUARD LEFT FLOOR (BLACK BRUT)	39,64 £ (45,08 €)
# 6	80125-LBD4-900	COLLAR FLOOR	1,89 £ (2,15 €)
# 7	80200-LCA5-E00-C3R	MUDGUARD REAR (BLUE)	44,62 £ (50,74 €)
# 7	80200-LCA5-E00-E4R	MUDGUARD REAR (RED)	44,62 £ (50,74 €)
# 7	80200-LCA5-E00-GWR	MUDGUARD REAR (DARK GREEN)	44,62 £ (50,74 €)
# 7	80200-LCA5-E00-YNR	MUDGUARD REAR (YELLOW)	44,62 £ (50,74 €)
# 7	80200-LCA5-E00-YSR	MUDGUARD REAR (SANDY)	44,62 £ (50,74 €)
# 8	83500-LCA5-E01-N1R	COVER RIGHT SIDE (BLACK BRUT)	14,81 £ (16,84 €)
# 9	8360A-LCA5-E01-N1R	COVER LEFT SIDE (BLACK BRUT)	14,81 £ (16,84 €)
# 9	8360A-LCA5-E00	COUVERCLE GAUCHE	Not available	0,00 £ (0,00 €)
# 10	90110-LLB1-800-06	SCREW PAN (M06X16)(BLACK)	2,18 £ (2,48 €)
# 11	90653-LCA4-E00	CLIP MUDGUARD	1,25 £ (1,42 €)
# 12	90677-GAR1-C00	ECROU PRISONNIER M5	Not available	0,00 £ (0,00 €)
# 13	93404-06016-06	BOLT HEX (M06X16)(BLACK)	1,39 £ (1,58 €)
# 14	93404-06020-06	BOLT HEX (M06X20)(BLACK)	1,39 £ (1,58 €)
# 15	93903-34360	SCREW TAPPING (M04X12)(BLACK)	1,28 £ (1,46 €)
# 16	93903-35360	SCREW TAPPING (M05X16)	1,28 £ (1,46 €)
# 17	94050-LDE9-E00	NUT LOCK (M06)	1,74 £ (1,98 €)
# 18	93903-GFY6-C00	VIS A TETE PLATE CRUCIFORME TARAUDEUSE DE 09 (M04X14 NOIR)	Not available	0,00 £ (0,00 €)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the REAR FAIRINGS of your Kymco MXU 300 4T EURO II of MXU. Let us know if you have any questions.
