TRANSMISSION

TRANSMISSION FOR KYMCO MXU 300 4T EURO II

VARIATOR / CLUTCH

(1) 23211-LCD9-E00

SHAFT MAIN TRANSMISSION

(2) 23411-LCD9-E00

SHAFT DRIVE

(3) 23420-PWA1-E00

SHAFT COUNTER

(4) 23440-PWA1-E00

GEAR FORWARD

(5) 23450-LCD9-E00

GEAR BACKWARD

(6) 23471-LCD9-E01

SHIFT REVERSE & LOWER

(7) 23481-PWA1-E00

SHIFT FORWARD

(8) 23518-LCD9-E00

PIGNON CONIQUE

(9) 23520-LCD9-E00

GEAR ASSY LOWER DRIVEN

(10) 24211-LCD9-E00

FORK RIGHT GEAR SHIFT

(11) 24221-LCD9-E00

FORK LEFT GEAR SHIFT

(12) 24241-LCD9-E00

SHAFT GEAR SHIFT FORK GUIDE

(13) 24242-LCD9-E00

GUIDE RIGHT FORK

(14) 24251-LCD9-E00

GUIDE RIGHT FORK

(15) 24305-PWA1-900

SPRING GEAR SHIFT PLATE

(16) 2431A-LCD9-E01

DRUM ASSY GEAR SHIFT

(17) 24610-LCD9-E00

SPINDLE COMP DRUM SHIFT

(18) 24651-LCD9-E00

SPRING GEAR SHIFT RETURN

(19) 24701-LCD9-E00

GEAR CHANGE HANDEL

(20) 90001-GFY6-C00

SOCKET BOLT (M06X10)(BLACK)

(21) KY-99-1000

REFERENCE NON RECONDUITE (NE PEUT PLUS &ECIRC;TRE COMMAND&EACUTE;E)

(22) 90401-LEA7-E00

WASHER THRUST (1,93X14,15X27,82)

(23) 90404-PWA1-E00

WASHER THRUST (25MM)

(24) 90441-LDE9-E00

WASHER 2 TROUS

(24) 90441-PWA1-E00

WASHER 3 TROUS

(25) 90447-KED9-900

WASHER THRUST (0,97X17,30X25,89)

(26) 90451-LBA7-900

WASHER THRUST (0,94X20,11X32,84)

(27) 90451-LBA7-900

WASHER THRUST (0,94X20,11X32,84)

(28) 90451-LDE9-E00

WASHER THRUST (2,95X20,12X32,87)

(29) 90452-LBA7-900

WASHER THRUST (1,01X25,24X39,91)

(30) 90455-LBA7-900

WASHER SPLINE (25MM)

(31) 90455-PWA1-E00

WASHER PLAIN (1,55X25,07X31,40)

(32) 90474-3C33-C00

WASHER-DRAIN PLUG (8MM)

(33) 90521-0H28-001

WASHER PLAIN (1,58X17,10X21,80)

(34) 90605-KED9-900

CIRCLIP IN (28MM)

(35) 91106-LBA7-90A

ROULEMENT A AIGUILLES 20X26X16

(36) 92101-06020-0H

BOLT HEX (M06X20)(GOLD)

(37) 94031-LCD9-E00

NUT (M16)

(38) 94510-25000

CIRCLIP EX (25MM)

(39) 94540-12028

CIRCLIP EX (12MM)

(40) 94540-LCD9-E00

CIRCLIP EX (15MM)

(41) 96100-63030-00

BEARING BALL (6303)(17X47X14)

	Part number	Description	Qty
# 1	23211-LCD9-E00	SHAFT MAIN TRANSMISSION	99,92 €(85,98 £)
# 2	23411-LCD9-E00	SHAFT DRIVE	87,42 €(75,22 £)
# 3	23420-PWA1-E00	SHAFT COUNTER	162,42 €(139,76 £)
# 4	23440-PWA1-E00	GEAR FORWARD	99,92 €(85,98 £)		Special offer 119,90 €(103,17 £)
# 5	23450-LCD9-E00	GEAR BACKWARD	95,75 €(82,39 £)
# 6	23471-LCD9-E01	SHIFT REVERSE & LOWER	26,58 €(22,87 £)		Special offer 31,90 €(27,45 £)
# 7	23481-PWA1-E00	SHIFT FORWARD	40,75 €(35,07 £)		Special offer 48,90 €(42,08 £)
# 8	23518-LCD9-E00	PIGNON CONIQUE	Not available	0,00 €(0,00 £)
# 9	23520-LCD9-E00	GEAR ASSY LOWER DRIVEN	76,58 €(65,90 £)
# 10	24211-LCD9-E00	FORK RIGHT GEAR SHIFT	56,58 €(48,69 £)
# 11	24221-LCD9-E00	FORK LEFT GEAR SHIFT	87,42 €(75,22 £)
# 12	24241-LCD9-E00	SHAFT GEAR SHIFT FORK GUIDE	4,75 €(4,09 £)
# 13	24242-LCD9-E00	GUIDE RIGHT FORK	19,92 €(17,14 £)
# 14	24251-LCD9-E00	GUIDE RIGHT FORK	20,75 €(17,86 £)
# 15	24305-PWA1-900	SPRING GEAR SHIFT PLATE	4,33 €(3,73 £)
# 16	2431A-LCD9-E01	DRUM ASSY GEAR SHIFT	95,75 €(82,39 £)
# 17	24610-LCD9-E00	SPINDLE COMP DRUM SHIFT	21,58 €(18,57 £)
# 18	24651-LCD9-E00	SPRING GEAR SHIFT RETURN	1,08 €(0,93 £)
# 19	24701-LCD9-E00	GEAR CHANGE HANDEL	9,58 €(8,24 £)
# 20	90001-GFY6-C00	SOCKET BOLT (M06X10)(BLACK)	1,33 €(1,14 £)
# 21	KY-99-1000	REFERENCE NON RECONDUITE (NE PEUT PLUS &ECIRC;TRE COMMAND&EACUTE;E)	Not available	0,00 €(0,00 £)
# 22	90401-LEA7-E00	WASHER THRUST (1, 93X14, 15X27, 82)	3,08 €(2,65 £)
# 23	90404-PWA1-E00	WASHER THRUST (25MM)	3,08 €(2,65 £)
# 24	90441-LDE9-E00	WASHER 2 TROUS	2,50 €(2,15 £)
# 24	90441-PWA1-E00	WASHER 3 TROUS	Not available	0,00 €(0,00 £)
# 25	90447-KED9-900	WASHER THRUST (0, 97X17, 30X25, 89)	1,00 €(0,86 £)
# 26	90451-LBA7-900	WASHER THRUST (0, 94X20, 11X32, 84)	1,50 €(1,29 £)
# 27	90451-LBA7-900	WASHER THRUST (0, 94X20, 11X32, 84)	1,50 €(1,29 £)
# 28	90451-LDE9-E00	WASHER THRUST (2, 95X20, 12X32, 87)	1,50 €(1,29 £)
# 29	90452-LBA7-900	WASHER THRUST (1, 01X25, 24X39, 91)	1,50 €(1,29 £)
# 30	90455-LBA7-900	WASHER SPLINE (25MM)	2,08 €(1,79 £)
# 31	90455-PWA1-E00	WASHER PLAIN (1, 55X25, 07X31, 40)	2,92 €(2,51 £)
# 32	90474-3C33-C00	WASHER-DRAIN PLUG (8MM)	0,75 €(0,65 £)
# 33	90521-0H28-001	WASHER PLAIN (1, 58X17, 10X21, 80)	0,67 €(0,58 £)
# 34	90605-KED9-900	CIRCLIP IN (28MM)	1,42 €(1,22 £)
# 35	91106-LBA7-90A	ROULEMENT A AIGUILLES 20X26X16	Not available	0,00 €(0,00 £)
# 36	92101-06020-0H	BOLT HEX (M06X20)(GOLD)	1,33 €(1,14 £)
# 37	94031-LCD9-E00	NUT (M16)	8,75 €(7,53 £)
# 38	94510-25000	CIRCLIP EX (25MM)	1,50 €(1,29 £)
# 39	94540-12028	CIRCLIP EX (12MM)	1,17 €(1,01 £)
# 40	94540-LCD9-E00	CIRCLIP EX (15MM)	5,42 €(4,66 £)
# 41	96100-63030-00	BEARING BALL (6303)(17X47X14)	7,92 €(6,82 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the TRANSMISSION of your Kymco MXU 300 4T EURO II of MXU. Let us know if you have any questions.
