FRONT AXLE

COOLING FOR KYMCO MXU 400 2X4 - 4X4 4T EURO II

BREATHER

11344

(11344) 11344-PWB1-900

DUCT BELT AIR OUT

11345

(11345) 11345-PWB1-900

DUCT LEFT COVER

11347

(11347) 11347-PWB1-900

CLAMP PLASTC-SCREW-OVAL

11349

(11349) 11346-PWB1-900

CLAMP PLASTC-SCREW-OVAL

11354

(11354) 11354-PWB1-900

BOOT AIR-IN

19005

(19005) 19005-PWB1-900

SHROUD ASSY

19020

(19020) 19020-PWB1-900

COOLER OIL

19028

(19028) 19028-PWB1-900

BUSHING STEM

19029

(19029) 19029-PWB1-900

RUBBER

19031

(19031) 19031-PWB1-900

BOLT FLANGE (M06X20)(BLACK)

19121

(19121) 19121-PWB1-900

HOSE OIL

19122

(19122) 19122-PWB1-900

HOSE ASSY OIL COOLER OUTLET

19504

(19504) 19504-LBA2-C00

CLAMP (16,8MM)

19508

(19508) 19508-LEE8-E00

CLAMP (20,0MM)

40201

(40201) 40201-PWB1-900

SHAFT ASSY REAR

40215

(40215) 40215-PWB1-900

BUMPER DRIVESHAFT

40502

(40502) 40502-PWB1-900

COVER GEARCASE

52101

(52101) 52101-PWB1-900

BOOT COUPLER

93404

(93404) 93404-06016-06

BOLT HEX (M06X16)(BLACK)

93903

(93903) 93903-45360

SCREW TAPPING (M05X16)(BLACK)

94050

(94050) 94050-06060

NUT (M06)

95111

(95111) 95111-PWB1-900

CLAMP BOOT

95112

(95112) 95112-PWB1-900

CLAMP (30,0MM)

95701

(95701) 95701-08020-06

BOLT FLANGE (M08X20)(BLACK)

	Part number	Description	Qty
# 11344	11344-PWB1-900	DUCT BELT AIR OUT	17,42 €(14,88 £)
# 11345	11345-PWB1-900	DUCT LEFT COVER	14,08 €(12,03 £)
# 11347	11347-PWB1-900	CLAMP PLASTC-SCREW-OVAL	3,92 €(3,35 £)
# 11349	11346-PWB1-900	CLAMP PLASTC-SCREW-OVAL	2,92 €(2,49 £)
# 11354	11354-PWB1-900	BOOT AIR-IN	9,58 €(8,18 £)
# 19005	19005-PWB1-900	SHROUD ASSY	141,58 €(120,92 £)
# 19020	19020-PWB1-900	COOLER OIL	204,08 €(174,29 £)
# 19028	19028-PWB1-900	BUSHING STEM	1,25 €(1,07 £)
# 19029	19029-PWB1-900	RUBBER	2,33 €(1,99 £)
# 19031	19031-PWB1-900	BOLT FLANGE (M06X20)(BLACK)	2,00 €(1,71 £)
# 19121	19121-PWB1-900	HOSE OIL	33,25 €(28,40 £)
# 19122	19122-PWB1-900	HOSE ASSY OIL COOLER OUTLET	28,25 €(24,13 £)
# 19504	19504-LBA2-C00	CLAMP (16, 8MM)	3,92 €(3,35 £)
# 19508	19508-LEE8-E00	CLAMP (20, 0MM)	3,58 €(3,06 £)
# 40201	40201-PWB1-900	SHAFT ASSY REAR	43,25 €(36,94 £)
# 40215	40215-PWB1-900	BUMPER DRIVESHAFT	1,42 €(1,21 £)
# 40502	40502-PWB1-900	COVER GEARCASE	34,92 €(29,82 £)
# 52101	52101-PWB1-900	BOOT COUPLER	5,75 €(4,91 £)
# 93404	93404-06016-06	BOLT HEX (M06X16)(BLACK)	1,33 €(1,14 £)
# 93903	93903-45360	SCREW TAPPING (M05X16)(BLACK)	Not available	0,00 €(0,00 £)
# 94050	94050-06060	NUT (M06)	1,42 €(1,21 £)
# 95111	95111-PWB1-900	CLAMP BOOT	3,58 €(3,06 £)
# 95112	95112-PWB1-900	CLAMP (30, 0MM)	3,08 €(2,63 £)
# 95701	95701-08020-06	BOLT FLANGE (M08X20)(BLACK)	2,25 €(1,92 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the COOLING of your Kymco MXU 400 2X4 - 4X4 4T EURO II of MXU. Let us know if you have any questions.
