FRAME FOR KYMCO MXU 400 2X4 - 4X4 4T EURO II

INDICATORS

50100

(50100) 50100-LFA5-E00

BODY COMP FRAME MXU 400

50614

(50614) 50614-PWB1-900

FOOTREST WELDMENT

54100

(54100) 54100-LFA5-E00

STAY ELECTRIC SET

77330

(77330) 77330-LFA5-E60-MAS

CARRIER REAR (BLACK)

77345

(77345) 77345-LFA5-E00

BARRE DE RENFORT ARRIERE

77352

(77352) 77352-LFA5-E00

TUBE REAR MOUNTING REAR RACK

77430

(77430) 77430-LFA5-E60-MAS

CARRIER FRONT (BLACK)

77438

(77438) 77437-LFA5-E00

TUBE REAR MOUNTING FRONT RACK

80110

(80110) 80110-LBA7-900

RUBBER REAR FENDER

81202

(81202) 81202-LDB5-E00

STAY NUMBER PLATE

83620

(83620) 83620-LFA5-E00

CAP PIPE

85100

(85100) 85100-LFA5-E00-MAS

PIPE COMP FRONT BUMPER (BLACK)

90301

(90301) 90301-6C93-001

NUT CAP (M06)

90304

(90304) 90304-GLW0-90A

NUT FLANGE (M10X10)

90652

(90652) 90652-LDB5-900

CLIP MUDGUARD

91307

(91307) 91307-PWB1-900

O-RING (14X10,82X1,778)

94050

(94050) 94050-08060

NUT (M08)

95701-08012

(95701-08012) 95701-08012-06

BOLT FLANGE (M08X12)(BLACK)

95701-08016

(95701-08016) 95701-08016-06

BOLT FLANGE (M08X16)(BLACK)

95801-08030

(95801-08030) 95801-08030-06

BOLT FLANGE (M08X30)(BLACK)

95801-08042

(95801-08042) 95801-08042-06

BOLT FLANGE (M08X42)(BLACK)

95801-08050

(95801-08050) 95801-08050-06

BOLT FLANGE (M08X50)(BLACK)

95801-10110

(95801-10110) 95801-10110-06

BOLT FLANGE (M10X110)(BLACK)

95801-10185

(95801-10185) 95801-10185-06

BOLT FLANGE (M10X185)(BLACK)

98501-08025

(98501-08025) 95801-08025-06

BOLT FLANGE (M08X25)(BLACK)

	Part number	Description	Qty
# 50100	50100-LFA5-E00	BODY COMP FRAME MXU 400	408,25 €(349,64 £)
# 50614	50614-PWB1-900	FOOTREST WELDMENT	31,58 €(27,05 £)
# 54100	54100-LFA5-E00	STAY ELECTRIC SET	2,50 €(2,14 £)
# 77330	77330-LFA5-E60-MAS	CARRIER REAR (BLACK)	124,92 €(106,99 £)
# 77345	77345-LFA5-E00	BARRE DE RENFORT ARRIERE	Not available	0,00 €(0,00 £)
# 77352	77352-LFA5-E00	TUBE REAR MOUNTING REAR RACK	56,58 €(48,46 £)
# 77430	77430-LFA5-E60-MAS	CARRIER FRONT (BLACK)	116,58 €(99,84 £)
# 77438	77437-LFA5-E00	TUBE REAR MOUNTING FRONT RACK	29,92 €(25,62 £)
# 80110	80110-LBA7-900	RUBBER REAR FENDER	1,25 €(1,07 £)
# 81202	81202-LDB5-E00	STAY NUMBER PLATE	9,58 €(8,20 £)
# 83620	83620-LFA5-E00	CAP PIPE	1,17 €(1,00 £)
# 85100	85100-LFA5-E00-MAS	PIPE COMP FRONT BUMPER (BLACK)	116,58 €(99,84 £)
# 90301	90301-6C93-001	NUT CAP (M06)	0,83 €(0,71 £)
# 90304	90304-GLW0-90A	NUT FLANGE (M10X10)	1,50 €(1,28 £)
# 90652	90652-LDB5-900	CLIP MUDGUARD	1,25 €(1,07 £)
# 91307	91307-PWB1-900	O-RING (14X10, 82X1, 778)	1,25 €(1,07 £)
# 94050	94050-08060	NUT (M08)	1,42 €(1,22 £)
# 95701-08012	95701-08012-06	BOLT FLANGE (M08X12)(BLACK)	1,50 €(1,28 £)
# 95701-08016	95701-08016-06	BOLT FLANGE (M08X16)(BLACK)	0,92 €(0,79 £)
# 95801-08030	95801-08030-06	BOLT FLANGE (M08X30)(BLACK)	1,50 €(1,28 £)
# 95801-08042	95801-08042-06	BOLT FLANGE (M08X42)(BLACK)	1,92 €(1,64 £)
# 95801-08050	95801-08050-06	BOLT FLANGE (M08X50)(BLACK)	2,00 €(1,71 £)
# 95801-10110	95801-10110-06	BOLT FLANGE (M10X110)(BLACK)	2,75 €(2,36 £)
# 95801-10185	95801-10185-06	BOLT FLANGE (M10X185)(BLACK)	4,75 €(4,07 £)
# 98501-08025	95801-08025-06	BOLT FLANGE (M08X25)(BLACK)	1,50 €(1,28 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FRAME of your Kymco MXU 400 2X4 - 4X4 4T EURO II of MXU. Let us know if you have any questions.
