FRONT FAIRINGS FOR KYMCO MXU 400 2X4 - 4X4 4T EURO II

RIGHT CASING

17700

(17700) 17700-LFA5-E00-CHR

COVER TANK (DARK BLUE)

(17700) 17700-LFA5-E00-E4R

COVER TANK (RED)

(17700) 17700-LFA5-E00-HGR

CARENAGE DE RESERVOIR (BLANC)

(17700) 17700-LFA5-E00-N1R

COVER TANK (BLACK BRUT)

(17700) 17700-LFA5-E00-Q2R

COVER TANK (LIGHT GREEN)

(17700) 17700-LFA5-E00-YSR

COVER TANK (SANDY)

31605

(31605) 31605-PWB1-900-N1R

TRAY ELECTRICAL (BLACK BRUT)

60100

(60100) 60100-LFA5-E00-CHR

FENDER FRONT (DARK BLUE)

(60100) 60100-LFA5-E00-E4R

FENDER FRONT (RED)

(60100) 60100-LFA5-E00-HGR

FENDER FRONT (WHITE)

(60100) 60100-LFA5-E00-N1R

FENDER FRONT (BLACK BRUT)

(60100) 60100-LFA5-E00-Q2R

FENDER FRONT (LIGHT GREEN)

(60100) 60100-LFA5-E00-YSR

FENDER FRONT (SANDY)

60102

(60102) 60102-PWB1-900

RUBBER PANELSIDE

60112

(60112) 60112-PWB1-900

RUBBER FRONT COVER

60113

(60113) 60113-PWB1-900

COLLAR RUBBER

60130

(60130) 60130-PWB1-910-N1R

PANEL SPLASH RIGHT (BLACK BRUT)

60140

(60140) 60140-PWB1-E01-N1R

PANEL SPLASH-LEFT (BLACK BRUT)

60150

(60150) 60150-LFA5-E01-N1R

PLATE SPLASH BOARD (BLACK BRUT)

60200

(60200) 60200-LFA5-E00-N1R

MUDGUARD FRONT (BLACK BRUT)

64300

(64300) 64300-PWB1-910

COVER UNDER

64301

(64301) 64301-LFA5-E00-N1R

COVER FRONT (BLACK BRUT)

64302

(64302) 64302-LFA5-E01-N1R

BUMPER FRONT (BLACK BRUT)

90110

(90110) 90110-PWB1-900

SCREW PAN (M06X20)(BLACK)

90652-LCA4

(90652-LCA4) 90652-LCA4-E00

CLIP MUDGUARD

90652-PWB1

(90652-PWB1) 90652-PWB1-900

CLIP MUDGUARD

90677

(90677) 90677-GAR1-C00

ECROU PRISONNIER M5

93404-06012

(93404-06012) 93404-06012-06

BOLT HEX (M06X12)(BLACK)

93404-06016

(93404-06016) 93404-06016-06

BOLT HEX (M06X16)(BLACK)

93903-35260

(93903-35260) 93903-35260

SCREW TAPPING (M05X12)

93903-PWB1-900

(93903-PWB1-900) 93903-PWB1-900

SCREW WASHER (M05X23)(BLACK)

94050

(94050) 94050-LDE9-E00

NUT LOCK (M06)

	Part number	Description	Qty
# 17700	17700-LFA5-E00-CHR	COVER TANK (DARK BLUE)	28,25 €(24,19 £)
# 17700	17700-LFA5-E00-E4R	COVER TANK (RED)	28,25 €(24,19 £)
# 17700	17700-LFA5-E00-N1R	COVER TANK (BLACK BRUT)	28,25 €(24,19 £)
# 17700	17700-LFA5-E00-Q2R	COVER TANK (LIGHT GREEN)	28,25 €(24,19 £)
# 17700	17700-LFA5-E00-YSR	COVER TANK (SANDY)	28,25 €(24,19 £)
# 17700	17700-LFA5-E00-HGR	CARENAGE DE RESERVOIR (BLANC)	Not available	0,00 €(0,00 £)
# 31605	31605-PWB1-900-N1R	TRAY ELECTRICAL (BLACK BRUT)	9,58 €(8,20 £)
# 60100	60100-LFA5-E00-CHR	FENDER FRONT (DARK BLUE)	95,75 €(81,98 £)
# 60100	60100-LFA5-E00-E4R	FENDER FRONT (RED)	95,75 €(81,98 £)
# 60100	60100-LFA5-E00-HGR	FENDER FRONT (WHITE)	95,75 €(81,98 £)
# 60100	60100-LFA5-E00-N1R	FENDER FRONT (BLACK BRUT)	95,75 €(81,98 £)
# 60100	60100-LFA5-E00-Q2R	FENDER FRONT (LIGHT GREEN)	95,75 €(81,98 £)
# 60100	60100-LFA5-E00-YSR	FENDER FRONT (SANDY)	95,75 €(81,98 £)
# 60102	60102-PWB1-900	RUBBER PANELSIDE	1,42 €(1,22 £)
# 60112	60112-PWB1-900	RUBBER FRONT COVER	0,83 €(0,71 £)
# 60113	60113-PWB1-900	COLLAR RUBBER	2,33 €(1,99 £)
# 60130	60130-PWB1-910-N1R	PANEL SPLASH RIGHT (BLACK BRUT)	7,92 €(6,78 £)
# 60140	60140-PWB1-E01-N1R	PANEL SPLASH-LEFT (BLACK BRUT)	14,08 €(12,06 £)
# 60150	60150-LFA5-E01-N1R	PLATE SPLASH BOARD (BLACK BRUT)	5,75 €(4,92 £)
# 60200	60200-LFA5-E00-N1R	MUDGUARD FRONT (BLACK BRUT)	33,25 €(28,47 £)
# 64300	64300-PWB1-910	COVER UNDER	28,25 €(24,19 £)
# 64301	64301-LFA5-E00-N1R	COVER FRONT (BLACK BRUT)	11,25 €(9,63 £)
# 64302	64302-LFA5-E01-N1R	BUMPER FRONT (BLACK BRUT)	24,08 €(20,62 £)
# 90110	90110-PWB1-900	SCREW PAN (M06X20)(BLACK)	1,67 €(1,43 £)
# 90652-LCA4	90652-LCA4-E00	CLIP MUDGUARD	1,25 €(1,07 £)
# 90652-PWB1	90652-PWB1-900	CLIP MUDGUARD	1,25 €(1,07 £)
# 90677	90677-GAR1-C00	ECROU PRISONNIER M5	Not available	0,00 €(0,00 £)
# 93404-06012	93404-06012-06	BOLT HEX (M06X12)(BLACK)	1,33 €(1,14 £)
# 93404-06016	93404-06016-06	BOLT HEX (M06X16)(BLACK)	1,33 €(1,14 £)
# 93903-35260	93903-35260	SCREW TAPPING (M05X12)	1,25 €(1,07 £)
# 93903-PWB1-900	93903-PWB1-900	SCREW WASHER (M05X23)(BLACK)	2,75 €(2,35 £)
# 94050	94050-LDE9-E00	NUT LOCK (M06)	1,67 €(1,43 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FRONT FAIRINGS of your Kymco MXU 400 2X4 - 4X4 4T EURO II of MXU. Let us know if you have any questions.
