CYLINDER / PISTON FOR KYMCO MXU 400 2X4 - 4X4 4T EURO II

STICKERS

12100

(12100) 12100-PWB1-900

CYLINDER COMP

12191

(12191) 12191-PWB1-900

GASKET CYLINDER

12251

(12251) 12251-PWB1-900

GASKET CYLINDER HEAD

13000

(13000) 13000-PWB1-900

CRANK SHAFT COMP

13011

(13011) 13011-PWB1-900

RING SET PISTON

13101

(13101) 13101-PWB1-900

PISTON

13111

(13111) 13111-PWB1-900

PIN PISTON (20X59)

13418

(13418) 13418-PWB1-900

GEAR BALANCER DRIVE

13421

(13421) 13421-PWB1-900

SHAFT COMP BALANCER

14401

(14401) 14401-PWB1-900

CHAIN CAM

14510

(14510) 14510-PWB1-900

TENSLONER CAM CHAIN

14531

(14531) 14531-PWB1-900

PIVOT CAM CHAIN TENSIONER

14550

(14550) 14550-LBA2-E00

LIFTER ASSY TENSIONER

14555

(14555) 14555-LBA2-E00

GASKET TENSIONER LIFTER

14610

(14610) 14610-PWB1-900

GUIDE COMP CAM CHAIN

15131

(15131) 15131-PWB1-900

SPROCKET OIL PUMP

15711

(15711) 15711-PWB1-900

WASHER PLAIN (2,43X10,21X30,00)

90205

(90205) 90205-LDB5-E00

NUT (M16)

90481

(90481) 90481-0E35-C00

WASHER PLAIN (1,08X8,39X13,98)

90701

(90701) 90701-LDB5-E00

KEY WOODRUFF (25X17X5)

91102

(91102) 91102-PWB1-900

BEARING CON-ROD

91206

(91206) 91206-PWB1-900

COLLAR

91302

(91302) 91302-PWB1-900

O-RING (15X12X2)

94050-06080

(94050-06080) 94050-06080

NUT (M06)

94050-08080

(94050-08080) 94050-08080

NUT (M08)

94050

(94050) 94050-10080

NUT FLANGE (M10X10)

94301

(94301) 94301-13220

PIN DOWEL (13X18)

94303

(94303) 94303-04065

PIN DOWEL (4X6,5)

94401

(94401) 94401-16150

KEY WOODRUFF (16X15)

94601

(94601) 94601-PWB1-900

CLIP PISTON PIN (20MM)

95701-06025

(95701-06025) 95701-06025-08

BOLT FLANGE (M06X25)(GOLD)

95701-PWB1

(95701-PWB1) 95701-PWB1-900

BOLT FLANGE (M10X20)(GOLD)

	Part number	Description	Qty
# 12100	12100-PWB1-900	CYLINDER COMP	199,92 €(171,19 £)
# 12191	12191-PWB1-900	GASKET CYLINDER	16,58 €(14,20 £)
# 12251	12251-PWB1-900	GASKET CYLINDER HEAD	37,42 €(32,04 £)
# 13000	13000-PWB1-900	CRANK SHAFT COMP	416,58 €(356,71 £)
# 13011	13011-PWB1-900	RING SET PISTON	28,25 €(24,19 £)
# 13101	13101-PWB1-900	PISTON	41,58 €(35,60 £)
# 13111	13111-PWB1-900	PIN PISTON (20X59)	11,25 €(9,63 £)
# 13418	13418-PWB1-900	GEAR BALANCER DRIVE	76,58 €(65,57 £)
# 13421	13421-PWB1-900	SHAFT COMP BALANCER	70,75 €(60,58 £)
# 14401	14401-PWB1-900	CHAIN CAM	87,42 €(74,86 £)
# 14510	14510-PWB1-900	TENSLONER CAM CHAIN	35,75 €(30,61 £)
# 14531	14531-PWB1-900	PIVOT CAM CHAIN TENSIONER	2,33 €(2,00 £)
# 14550	14550-LBA2-E00	LIFTER ASSY TENSIONER	37,42 €(32,04 £)
# 14555	14555-LBA2-E00	GASKET TENSIONER LIFTER	1,50 €(1,28 £)
# 14610	14610-PWB1-900	GUIDE COMP CAM CHAIN	28,25 €(24,19 £)
# 15131	15131-PWB1-900	SPROCKET OIL PUMP	21,58 €(18,48 £)
# 15711	15711-PWB1-900	WASHER PLAIN (2, 43X10, 21X30, 00)	2,92 €(2,50 £)
# 90205	90205-LDB5-E00	NUT (M16)	8,75 €(7,49 £)
# 90481	90481-0E35-C00	WASHER PLAIN (1, 08X8, 39X13, 98)	0,67 €(0,57 £)
# 90701	90701-LDB5-E00	KEY WOODRUFF (25X17X5)	1,92 €(1,64 £)
# 91102	91102-PWB1-900	BEARING CON-ROD	87,42 €(74,86 £)
# 91206	91206-PWB1-900	COLLAR	7,92 €(6,78 £)
# 91302	91302-PWB1-900	O-RING (15X12X2)	1,00 €(0,86 £)
# 94050	94050-10080	NUT FLANGE (M10X10)	1,42 €(1,22 £)
# 94050-06080	94050-06080	NUT (M06)	1,42 €(1,22 £)
# 94050-08080	94050-08080	NUT (M08)	1,42 €(1,22 £)
# 94301	94301-13220	PIN DOWEL (13X18)	1,83 €(1,57 £)
# 94303	94303-04065	PIN DOWEL (4X6, 5)	1,50 €(1,28 £)
# 94401	94401-16150	KEY WOODRUFF (16X15)	1,92 €(1,64 £)
# 94601	94601-PWB1-900	CLIP PISTON PIN (20MM)	0,67 €(0,57 £)
# 95701-06025	95701-06025-08	BOLT FLANGE (M06X25)(GOLD)	1,33 €(1,14 £)
# 95701-PWB1	95701-PWB1-900	BOLT FLANGE (M10X20)(GOLD)	2,33 €(2,00 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CYLINDER / PISTON of your Kymco MXU 400 2X4 - 4X4 4T EURO II of MXU. Let us know if you have any questions.
