REAR SUPENSION FOR KYMCO MXU 400 2X4 - 4X4 4T EURO II

FRONT SUPENSION / STEERING COLUMN

47450

(47450) 47450-PWB1-900

KNUCKLE REAR ASSY RIGHT

47452

(47452) 47452-PWB1-900

BUSHING REAR KNUCKLE

47453

(47453) 47453-PWB1-900

COLLAR

47550

(47550) 47550-PWB1-900

KNUCKLE REAR ASSY RIGHT

52103

(52103) 52103-PWB1-900

SLEEVE SUSPENSION

52104

(52104) 52104-PWB1-900

SLEEVE SUSPENSION

52108

(52108) 52108-PWB1-900

BUSH SWING ARM

52144

(52144) 52144-PWB1-900

DUST SEAL

52400

(52400) 52400-PWB1-900-MAS

CUSHION ASSY REAR (BLACK)

(52400) 52400-PWB1-900-MBS

CUSHION ASSY REAR (GREY)

54400

(54400) 54400-PWB1-E00-MAS

ARM ASSY REAR RIGHT SWING UP (BLACK)

(54400) 54400-PWB1-E00-MBS

ARM ASSY REAR RIGHT SWING UP (GREY)

54450

(54450) 54450-LFA5-E00-MAS

ARM ASSY REAR RIGHT SWING LOW (BLACK)

(54450) 54450-LFA5-E00-MBS

ARM ASSY REAR RIGHT SWING LOW (GREY)

54500

(54500) 54500-PWB1-E00-MAS

ARM ASSY REAR LEFT SWING UP (BLACK)

(54500) 54500-PWB1-E00-MBS

ARM ASSY REAR LEFT SWING UP (GREY)

54550

(54550) 54550-LFA5-E00-MAS

ARM ASSY REAR LEFT SWING LOW (BLACK)

(54550) 54550-LFA5-E00-MBS

ARM ASSY REAR LEFT SWING LOW (GREY)

90304

(90304) 90304-GLW0-90A

NUT FLANGE (M10X10)

94520

(94520) 94520-55000

CIRCLIP IN (55MM)

95801-10065

(95801-10065) 95701-10065-08

VIS EPAULEE A TETE HEXAGONALE DE 14 (M10X65/27 OR)

95801-10040

(95801-10040) 95801-10040-08G

BOLT FLANGE (M10X40)(GOLD)

95801-10085

(95801-10085) 95801-10085-06

BOLT FLANGE (M10X85)(BLACK)

95801-10095

(95801-10095) 95801-10095-06

BOLT FLANGE (M10X95)(BLACK)

95802

(95802) 95802-PWB1-900

BOLT FLANGE (M10X1.25)(BLACK)

96151

(96151) 96151-PWB1-900

BEARING WHEEL (ATI 1402-809)

	Part number	Description	Qty
# 47450	47450-PWB1-900	KNUCKLE REAR ASSY RIGHT	174,92 €(151,00 £)
# 47452	47452-PWB1-900	BUSHING REAR KNUCKLE	16,58 €(14,31 £)
# 47453	47453-PWB1-900	COLLAR	8,75 €(7,55 £)
# 47550	47550-PWB1-900	KNUCKLE REAR ASSY RIGHT	174,92 €(151,00 £)
# 52103	52103-PWB1-900	SLEEVE SUSPENSION	9,58 €(8,27 £)		Special offer 11,50 €(9,93 £)
# 52104	52104-PWB1-900	SLEEVE SUSPENSION	4,75 €(4,10 £)		Special offer 5,70 €(4,92 £)
# 52108	52108-PWB1-900	BUSH SWING ARM	4,33 €(3,74 £)
# 52144	52144-PWB1-900	DUST SEAL	2,50 €(2,16 £)
# 52400	52400-PWB1-900-MAS	CUSHION ASSY REAR (BLACK)	154,08 €(133,01 £)
# 52400	52400-PWB1-900-MBS	CUSHION ASSY REAR (GREY)	154,08 €(133,01 £)
# 54400	54400-PWB1-E00-MAS	ARM ASSY REAR RIGHT SWING UP (BLACK)	87,42 €(75,47 £)
# 54400	54400-PWB1-E00-MBS	ARM ASSY REAR RIGHT SWING UP (GREY)	87,42 €(75,47 £)
# 54450	54450-LFA5-E00-MAS	ARM ASSY REAR RIGHT SWING LOW (BLACK)	124,92 €(107,84 £)
# 54450	54450-LFA5-E00-MBS	ARM ASSY REAR RIGHT SWING LOW (GREY)	124,92 €(107,84 £)
# 54500	54500-PWB1-E00-MAS	ARM ASSY REAR LEFT SWING UP (BLACK)	87,42 €(75,47 £)
# 54500	54500-PWB1-E00-MBS	ARM ASSY REAR LEFT SWING UP (GREY)	87,42 €(75,47 £)
# 54550	54550-LFA5-E00-MAS	ARM ASSY REAR LEFT SWING LOW (BLACK)	124,92 €(107,84 £)
# 54550	54550-LFA5-E00-MBS	ARM ASSY REAR LEFT SWING LOW (GREY)	124,92 €(107,84 £)
# 90304	90304-GLW0-90A	NUT FLANGE (M10X10)	1,50 €(1,29 £)
# 94520	94520-55000	CIRCLIP IN (55MM)	5,75 €(4,96 £)
# 95801-10040	95801-10040-08G	BOLT FLANGE (M10X40)(GOLD)	3,25 €(2,81 £)
# 95801-10085	95801-10085-06	BOLT FLANGE (M10X85)(BLACK)	2,75 €(2,37 £)
# 95801-10095	95801-10095-06	BOLT FLANGE (M10X95)(BLACK)	2,75 €(2,37 £)
# 95801-10065	95701-10065-08	VIS EPAULEE A TETE HEXAGONALE DE 14 (M10X65/27 OR)	Not available	0,00 €(0,00 £)
# 95802	95802-PWB1-900	BOLT FLANGE (M10X1.25)(BLACK)	7,08 €(6,11 £)
# 96151	96151-PWB1-900	BEARING WHEEL (ATI 1402-809)	34,08 €(29,42 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the REAR SUPENSION of your Kymco MXU 400 2X4 - 4X4 4T EURO II of MXU. Let us know if you have any questions.
