1. GENERAL INFORMATION K-XCT 125i
TORQUE VALUES
Item Qty Thread dia.(mm) Torque (kgf-m) Remarks
Cylinder head bolt A 6 0.7~1.1
Cylinder head bolt B 6 0.7~1.1
Oil filter screen cap 30 2.0~3.0
O2 sensor 12 0.7~1.1
Cylinder head cover 6 0.8~0.9
Tappet adjusting hole cap 30 1.0~2.0
Cam chain set plate 6 1.0~1.4
Engine oil drain bolt 12 2.0~3.0
Clutch outer nut 12 5.0~6.0
Clutch drive plate nut 28 5.0~6.0
Starter motor mounting bolt 6 0.8~1.2
Oil pump bolt 6 0.7~1.1
Drive face nut 12 5.5~6.5
Spark plug 10 1.0~1.4
A.C. Generator flywheel 12 5.0~6.0
Cam chain tensioner pivot 6 0.8~1.2
1-8
