13. FRAME COVERS
REAR UPPER FENDER & TAILLIGHT
REMOVAL/INSTALLATION
Remove the following: (1)
Met-in box ( 13-5)
Rear carrier ( 13-5)
Center cover ( 13-6)
Rear body cover ( 13-6)
Remove the two bolts from the taillight and
two nuts from the rear upper fender.
Slide the two clips (1) for disconnect fuel hose
and vacuum hose (2).
Remove the rear upper fender/taillight.
Installation is in the reverse order of removal.
BOTTOM COVER
REMOVAL/INSTALLATION
Remove the right and left side covers. ( 13-4)
Remove the nut from the bottom cover left
side.
13-7
