14.STEERING HANDLEBAR/FRONT WHEEL/FRONT BRAKE/FRONT SHOCK ABSORBER/FRONT FORK GRAND DINK 125/150 Check the piston for scratches or wear. Measure the piston O.D. with a micrometer gauge. Service Limit: 25.30mm Check the caliper cylinder for scratches or wear and measure the cylinder bore. Service Limit: 25.45mm ASSEMBLY Clean all removed parts. Apply silicon grease to the piston and oil seal. Lubricate the brake caliper cylinder inside wall with brake fluid. Install the brake caliper piston with grooved side facing out. Install the piston with its outer end protruding 35mm beyond the brake caliper. Wipe off excessive brake fluid with a clean shop towel. Apply silicon grease to the brake caliper seat pin and caliper inside. Install the brake caliper seat. INSTALLATION Install the brake caliper to the shock absorber and tighten the two bolts. Torque: 24.534.3N-m When installing the brake caliper, be sure to position the brake disk between the two brake pads. Brake Caliper 14-12
