          3. INSPECTION/ADJUSTMENT                                                    GRAND DINK 250

                                                      Oil Dipstick
 ENGINE OIL
 OIL LEVEL INSPECTION
 Stop the engine and support the motorcycle
 upright on level ground.
 Wait for 23 minutes and check the oil level
 with the dipstick. Do not screw in the
 dipstick when making this check.




 OIL CHANGE
 · Drain the oil while the engine is warm.
 Remove the oil drain bolt to drain the engine
 oil.
 Install the aluminum washer and tighten the
 oil drain bolt.
 Torque: 14.7N-m
 · Replace the aluminum washer with a
     new one if it is deformed or damaged.                     Oil Filter Screen Cap
 Pour the recommended oil through the oil
 filler hole.
 Oil Capacity:
    At disassembly: 1.1 liter
    At change: 0.9 liter
 Recommended Oil:
    SAE: 15W40#
    API: SJ
 Start the engine and check for oil leaks.
 Stop the engine and recheck the oil level.



 OIL FILTER SCREEN INSPECTION
 Drain the engine oil.
 Remove the oil filter screen and spring.
 Clean the oil filter screen.
 Install the oil filter screen, spring, and filter
 screen cap.
 Fill the engine with recommended engine oil.




                                                     Oil Filter Screen                 Spring

                                                                                                3-4
