11. FRONT WHEEL/SUSPENSION/
STEERING K-PIPE 125
ASSEMBLY Bearing Driver Handle
Pack all bearing cavities with grease. First
drive in the right bearing and then install the
distance collar. Finally, drive in the left
bearing.
Special
Bearing driver handle
Bearing installer
Attachment, 37x40mm
Apply grease to the dust seal and install the
dust seal.
Install the brake disk and tighten the five
nuts.
Dust Seal
Groove
Install the speedometer gearbox by aligning
the tabs with the grooves.
Tabs
Speedometer Gearbox
Apply grease to the speedometer gearbox
and dust seal, then install them to the wheel
from the left side.
Dust Seal
11-9
