9. DRIVE AND DRIVEN PULLEYS/
KICK STARTER PEOPLE 125/150
KICK STARTER Kick Lever
REMOVAL
Remove the left crankcase cover. ( 9-2)
Remove the seal rubber and dowel pins.
Remove the kick lever.
Remove the circlip and washer from the kick
starter spindle.
Kick Starter Spindle
Starter Driven Gear
Gently turn the kick starter spindle to remove
the starter driven gear together with the
friction spring.
Friction Spring
Remove the kick starter spindle and return Kick Starter Spindle
spring from the left crankcase cover.
Remove the kick starter spindle bushing.
Return Spring
Spindle Plastic Bushing
INSPECTION
Inspect the kick starter spindle and gear for
wear or damage.
Inspect the return spring for weakness or
damage.
Inspect the kick starter spindle bushings for
wear or damage.
Return Spring Spindle Bushing
9-14
