8. CYLINDER HEAD/VALVES UXV 500
Install the cam chain over the cam sprockets Punch Marks
and then install the intake and exhaust
camshafts.
Install each camshafts to the correct
locations.
"IN": no decompressor cam
"EX": has a decompressor cam
Make sure the timing marks on the cam
sprockets are flush with the cylinder
head upper surface and punch marks Timing Marks
face upward as shown.
Install intake and exhaust camshaft holders to
the correct locations.
Install each camshaft holders to the
correct locations.
"IN": no stop pin.
"EX": has a stop pin.
Exhaust Camshaft Holder Stop Pin
8-12
